Case Study

1.Pennant Overview

Pennant is a collaborative computational notebook for web development students and professionals that brings note-taking, code execution, and real-time collaboration to a single platform.

As a cloud-based tool, Pennant requires no installation, allowing users to get started quickly and providing secure server-side code execution. And importantly, Pennant supports seamless real-time collaboration as students and professionals become increasingly remote.

This white paper will generally explore the technical challenges of computational notebooks, such as code execution and real-time user collaboration, our team’s specific architectural decisions to overcome those challenges, and the resulting tradeoffs from those decisions. We’ll explore each of these technical choices in depth and our final architecture, but first, we’ll provide a brief background on the product domain.

1.1 Computational Notebooks

Computational notebooks allow users to write, document, and execute code in a single tool. Unlike scripts, Pennant segments code into cells that enable users to run sections of code step-by-step, displaying immediate, inline results directly below the executed cell. This empowers users to experiment with their code, and users can receive immediate feedback on how changing their code influences the output.

Computational notebooks facilitate the creation of detailed notes through cells with markdown functionality. Markdown cells render text, images, and other elements to deliver rich and visually engaging documentation notes. Consequently, data scientists and researchers utilize computational notebooks as a primary tool for exploring datasets and sharing findings.

Computational notebooks are also viable for learning. Students from diverse academic fields can learn how to code with Jupyter Notebook with no prior experience. Instructors can create interactive lecture notes while students can experiment with code snippets on the same notebook [1]. Computational notebooks also circumvent technical setup requirements that can be difficult for beginners, such as setting up development environments [2].

1.2 How Pennant is Used

Pennant brings the educational benefits of using computational notebooks to web development students. Unlike note-taking tools like Notion and Obsidian, a computational notebook allows users to read tutorials, take notes, and experiment with code in one place.

Pennant is more suited for learning JavaScript than existing computational notebooks. The quirks and idiosyncrasies of the language present a challenge when attempting to deliver accurate and consistent variable state across all cells and all edge cases.

Other web development notebooks require users to learn non-standard flavors of Javascript to account for the difficulties of non-linear notebook-style code execution. For example Observable [3] chose an implementation tradeoff that simply bans all variable declarations to circumvent syntax errors.

In contrast, Pennant preserves standard JavaScript syntax while allowing notebook-style code execution through our code execution engine optimizations. By featuring vanilla Javascript, students can use the same language conventions they would anywhere else.

Pennant notebooks allow seamless, real-time collaboration for up to 5 users per notebook.

User interactions, including cursor movements, text inputs, and highlighting, are visible in ‘real time’, and updates are automatically saved without conflicts.

Each notebook is paired with a dedicated, server-side execution engine, and all collaborators have access to code execution without any technical setup requirements (e.g., VS Code Live Share) or additional tools (like Coderpad).

You can try out Pennant here.

2. Real-time Collaboration

The standard definition of real-time collaboration refers to the capability allowing multiple individuals to simultaneously work on a shared piece of data, whether it's a rich text document, a presentation, or simple task descriptions.

While many applications tout real-time features, not all demand collaborative editing. For instance, a live news feed updates in real-time but doesn't involve mutual data contribution. Moreover, certain write-intensive apps limit simultaneous editing or use mechanisms like 'locks' to avert conflicts.

Most real-time collaboration applications have similar technical challenges involved in their architecture. In the following subsections, we’ll explore some of those challenges in the context of collaborative computational notebooks along with the tradeoffs that influenced Pennant’s technical decisions. Following our exploration of challenges tied to code execution within these notebooks, we'll delve into Pennant’s overarching architecture.

Real-time collaboration presents many specific challenges such as:

  • Sharing state across all users with minimal latency.
  • Resolving conflicting state updates from multiple users
  • Broadcasting presence and awareness data in “real-time”

In the next section, we will discuss the workflows that existed before collaborative applications and the problems that led to the emergence of the collaborative model.

2.1 The historical model

2.1.1 Request response model

Before the rise of collaborative applications, documents resided in shared data sources (e.g., shared hard drive, server, or database). All users collaborating on a document should reasonably expect the document on the data store to be the single source of truth for its current state. Users request the document and create a local copy on their machine. The user modifies the local copy and, at an undetermined point in the future, saves that local copy back to the shared data source.

2.1.2 Overwriting and Lockouts

The historical model, in its primitive form, made it easy for document updates to be unintentionally overwritten. Imagine multiple users each working on their local copies of a shared document. As one user saves their local copy back to the central store, they might inadvertently overwrite another user's recently saved changes. This is visually depicted below, where the left user's save action erases the updates made by the user on the right.

To mitigate such overwrite issues, many systems employed a "lockout" mechanism. In this approach, once User A accesses a document, the central store locks it, ensuring its consistency. Any subsequent access requests, say from User B, are denied until User A's lock is released. While this approach guarantees the document's strong consistency in storage, it significantly hamstrings real-time collaboration, as multiple users can't simultaneously edit the document.

2.2 The collaborative model

2.2.1 Streaming Model for Real-Time Synchronization

The collaborative model is a departure from the historical model's constraints. Unlike the historical model, where overwrite issues often led to the implementation of a "lockout" mechanism, the collaborative model promotes uninterrupted collaboration. It ensures real-time synchronization across user versions, effectively eliminating the possibility of interaction with stale states.

It emphasizes quick, consistent updates, often applied at every keystroke or word completion. While updates can occur at longer intervals to save computational resources, the goal is to converge all client versions to a unified state with each document update.

However, achieving this real-time collaboration brings challenges such as latency, network reliability, and the need for efficient mechanisms to handle concurrent updates.

2.2.2 Requirements of the collaborative model

To fully harness the potential of the collaborative model, it's essential to understand and cater to its unique data requirements:

A. Real-time latency

Pennant is text based and must be performant in a way that users expect. We need to ensure that our latency in updating states aligns with other well-known collaborative products like Google Docs.

B. Conflict resolution and eventual consistency

All users must eventually see the same content on their browsers. Our conflict resolution must occur within the expected real-time latency window.

C. Automatic updates

As users collaborate, remote updates must be seamlessly merged on screen.

D. Presence & Awareness

Users should be able to see who is changing what and where. The visual conventions are relatively well established for text-based applications: text highlighting, cursor highlighting and distinct icons for active users. The data streamed for awareness and presence is generally considered ephemeral and is not typically logged or stored to disk.

2.3 Challenges in Code Execution

Code execution presents many technical challenges such as:

  • Allowing for flexible ‘notebook-style’ code execution
  • Securing client-submitted code execution and minimizing performance costs of implementing these security measures
  • Designing for the unique challenges of running code collaboratively

In this section, we will explore some technical challenges involved in designing a performant code execution engine. We will first look at two fundamentally different models of code execution along with their tradeoffs. Then, we will look at how execution engines securely run code and the performance costs of implementing safety measures. Finally, we will look at the unique challenges of running code collaboratively.

2.3.1 More flexible code execution

There are two broad models of code execution, with one of them generic to typical code execution and the other one specific to notebooks.

In the generic model, when code is executed, the code in a file runs from top to bottom. If there are computationally heavy parts of the code, the entire file needs to be run each time it is edited and tested. In some cases, complex code (for example uploading a large database or running an AI model) can run for hours or days or more.


The original use case for notebooks was specifically to reduce the computational load for researchers who wanted to load data once, and then experiment with that data over time. Notebooks can save these users hours or more of time.

However, notebooks save time even when playing with code without a database, and often clarify code testing. Users can add new cases to test in new cells. Users of notebooks hit play right on that cell they want to test, and receive outputs right below that cell. This makes testing code easier and more organized.

Generic code execution engines can be computationally intensive, but they are less complex and also can save resources. This is because they do not have to accumulate and store any of the previous code executions.

By contrast, Notebooks give flexibility in code execution and allow easy visual segmentation, but come with the tradeoffs of increased memory usage and complexity of design . This is because notebooks have to accumulate and store data on all of the previous code executions.

2.3.2 Safe code execution

No matter which type of code execution engine you are building, the primary concern is that running a client’s code is dangerous. There are many ways in which untrusted code can pose a threat, either maliciously or by accident. It is impossible to filter for every dangerous situation and reduce the threat of running client code to zero.

For this reason, most code execution engines implement sandboxing mechanisms, creating an isolated environment inside a program from which untrusted code cannot escape. This minimizes the attack surface area and limits harmful effects on the code base or sensitive user data.

Isolation of user code can keep an app and its users safe, but it can be complicated to implement and consumes a large amount of overhead memory and space. In the past, this was the realm of specialists because its implementation was specific to each operating system. To add to the complexity, there were also layers of configuration that had to be completed separately on each machine.

Due to advances in sandboxing and container technology, engineers no longer need to configure individual machines, making sandboxing somewhat easier. Containers are isolated processes that can be passed between different operating systems with code inside. Users of containers can add sandboxing mechanisms that apply to all containers on the network. While the isolation of processes has become somewhat easier, it still requires a substantial amount of additional memory and space. Especially if a sandbox is built around a container, building these two layers of isolation can use more memory than the code it holds.

1.3.3 Collaborative code execution

Unlike text-editor collaborations, where changes can be made on your version and shipped to all other versions, code collaborations require all code to be sent to and executed on one central location. This central bottleneck actually benefits code execution engines, because it ensures that the users share one history, one context in which they all run their code.

In coderpad and most code collaboration, code can be executed in a stateless fashion, which means each time you hit play, the code can be executed anywhere, on any server, regardless of where your teammates code has been sent. Each code submission does not access any shared data from any previous submissions. That is why in the below example, the second user-submission has no access to the value of x from the first user-submission.

In Pennant and other notebooks, code execution is stateful. Each code submission needs access to the context from previous executions.

This means all code from a notebook needs to be submitted to the same engine instance.

Why can’t changes in code execution context just be shipped from user to user like document updates? Nobody does this because it is extremely difficult, or impossible, to send execution context from user to user. Therefore code execution needs to be centralized on a server.


3: Implementation

3.1 Infrastructure needs

We’ve covered the general problems associated with real-time collaboration and code execution and how they relate more specifically to computational notebooks. Now we’ll cover the details of Pennant’s architectural decisions to address those challenges and the technical tradeoffs made along the way. In this section, we will explore the four core components of Pennant and how we arrived at their design and implementation.

Pennant is made up of the following components:

  1. The client app, built as a single page React application . The application must detect changes to the underlying state of our document and reflect those changes to collaborator
  2. An execution enginewe can make API calls to, i.e., sending code extracted from our Notebook cells for execution.
  3. A web server for hosting our single page application and managing user and notebook metadata
  4. A collaboration service to coordinate state updates and awareness for all users.

The scaling needs of stateful collaborative applications lend themselves to a microservices architecture . As we will see, the collaboration service has the highest bandwidth needs, followed by the execution engine. On a per-user basis, the webserver and user management service receives the fewest requests. The Collaboration Service and the Execution engine will need to scale well before the Web server, so we began building our architecture with these services functionally separated from one another.

The Pennant browser application interacts with these services separately rather than via a single API. We could have kept the Code Execution service and Collaboration service APIs private. Requests requiring interaction with those services would be handled by application logic in the web server. However, this would have added additional latency to each request to the Execution Engine and Collaboration service. Given the importance of low latency in a collaborative application we decided to have the browser application interact with these services directly. The implementation and specific challenges of each service will be explained in later sections.

3.1.1 P2P vs Client Server

In the process of building Pennant, we had to make some critical decisions about our infrastructure needs. The technology underlying Pennant can support a peer-to-peer (p2p) model, which would allow notebooks to be used on closed networks or without touching Pennant-owned infrastructure. But, a client-server model is best for collaborations with more than 2 users.

The advantage of the p2p model is that we could move the computational load of code execution off of our infrastructure onto the client machines. The functionality of the execution engine and the collaboration service could be accomplished in the client browser. This would have reduced the complexity of our hosted infrastructure. Even the routing logic of the web server can be replicated in the client application.

The two primary disadvantages of the p2p model are divergent execution engine states and diminished client side performance. There are security implications for the execution of untrusted code as well, which will be discussed later in the Execution Engine section. At a network level, peer to peer would require the browser of each Notebook user to stream data to every other Notebook user, creating bandwidth, networking and performance burdens on the end user.

Instead, we opted for the client/server model. In this model, updates from users are streamed to the server. The server then handles conflict resolution, input sanitation, and broadcasts updates to all users of a document. Having state and awareness data flow through Pennant architecture also gives our team greater insight into usage patterns and application performance in order to facilitate future development. These tradeoffs led us to the more conventional client-server model.

Comparison Table: P2P vs. Client/Server Model

3.1.2 A pub/sub model

We had chosen a client-server model for the implementation of our collaboration service. This is the typical choice in a collaboration app with more than 2 collaborators because p2p models require more connections which are costly and create performance issues on the network.

We were able to leverage our client-server model to have the server broadcast changes out to all clients. An easy mental model is to think of each of our users as being able to publish changes to the Pennant Notebook and also being subscribed to any changes made in the notebook.

The client acts as the publisher and reports changes as they occur. A websocket server acts as the broker because it maintains connections to all the remote users who act as subscribers. The changes are incorporated on the remote user.

However, in our collaboration service, all clients act as both publishers and subscribers to all other clients.

3.2. Understanding the Problem: Collaboration in Real-Time

In real-time collaborative applications, the way you shape your data model can either simplify or complicate the task of managing state between multiple users. Imagine a scenario where concurrent updates are happening to multiple replicas. This can easily lead to inconsistencies. We found ourselves asking:

  1. How do we allow multiple users to work on the same document seamlessly?
  2. And how can we resolve those inconsistencies that are bound to arise?

We obviously needed efficient algorithms for convergence and consistency.

3.3. Algorithms for state convergence

In our search for an optimal algorithm to handle concurrency and synchronization, we researched how giants like Google Docs and Confluence tackled the problem. Each had utilized different and competing general models for handling merges and concurrency.

Google Docs employs Operational Transformation (OT) , where each document change is an operation sent to the server, which maintains the master document. The server serializes operations and returns them to clients, and ensures all users see all changes in server-determined order . This model centralizes data by channeling all changes through a single source of truth, or singular document copy, and introduces a single point of failure . However, due to the finite operation propagation speed and varying participant states, the resulting combinations of states and operations can be unpredictable.

On the other hand, Confluence, a team collaboration platform, uses a technology called Synchrony, which is based on Conflict-free Replicated Data Types (CRDTs). In this model, there is no centralized shared copy of the document. Every user's browser maintains its own replica of the document. When a user makes a change, that change is propagated to all other replicas. The CRDT algorithms ensure that all replicas can be updated independently and concurrently without conflicts, leading to eventual consistency across all replicas . However, the CRDT model requires more memory and computational power on the client side, which could impact performance on less powerful devices.

Comparison Table: Centralized vs. Decentralized Systems

3.4. Yjs: The Chosen CRDT

Our search led us to Yjs, a CRDT implementation designed for collaborative web applications. While CRDT-based applications, including Yjs, often face scrutiny over potential memory and performance overheads, it’s worth noting that Yjs has made significant advances in mitigating those concerns.

Despite the steep learning curve associated with its complex API, Yjs emerged as a compelling choice for our project. It offered a blend of speed, efficiency, real-time syncing and robust conflict resolution. Thus, despite the trade-offs, we were confident that it was the most suitable choice for Pennant.

3.5. The Mechanism Behind Yjs

Insertions

Yjs handles insertions using a sequential CRDT model. Each change is accompanied by an incremented monotonic clock. The id of the user who made the update is also recorded to the update. The combination of the clock state and the user id create a compound key. This key not only represents the data from an application perspective but also houses a substantial volume of metadata essential for conflict resolution.

Visualize this with a simple string creation. Let’s say a user writes the letter ‘F’. This is the first update of the string, so the clock state is 0. The combination of this clock state and the user's unique ID forms a compound key that points to our data, 'F', and the associated metadata necessary for conflict resolution.

Yjs maintains the current state of this data in a doubly linked list format . Each new data point or modification gets interlinked with previous and subsequent entries, creating a holistic view of where an update belongs.

If another user inserts a letter, say another lowercase ‘o’ between ‘F’ and ‘o’, the system recalibrates, updating the references in the list to accommodate this change. Therefore, the resultant value changes to ‘Foo’.

Deletions

Deletions utilize a state-based CRDT model. Deleted items are simply marked, without storing extensive metadata. With garbage collection, replaced content becomes lightweight, ensuring system efficiency.

Transactions & Commutativity

All Yjs alterations are enveloped in transactions, which, upon local finalization, get dispatched to peers as compressed update messages. Importantly, these document updates are commutative and associative, meaning they can be grouped and applied in any order and repetitively. They are also idempotent , meaning duplicate operations don’t change the result.

All of these properties help to maintain consistency in distributed systems. They ensure that variations in the order of event delivery or repeated message delivery do not lead to inconsistencies.

You can learn more about these operations in the Yjs Docs.

3.6. Conflict resolution in Yjs

Yjs stands out for its unique approach to conflict resolution, as visualized in the diagram below, starting with 'WXYZ'. At clock 0, two simultaneous insertions occur between W and X by users 0 and 1. The algorithm prioritizes lower user IDs, executing user 0's insertion first and user 1's second, resulting in 'WABXYZ'.

Why favor lower user IDs? It doesn’t matter. It could prioritize higher user IDs instead. The important thing is having a consistent rule and sticking to it so that all replicas can resolve conflicts the same way and converge to the same state. This approach ensures a seamless conflict resolution process, as the final document state remains consistent regardless of the order in which updates are received and applied.

In summary, by implementing Yjs, Pennant is able to offer its users:

  1. Online status and cursor position synchronization
  2. Offline editing capabilities
  3. Resilience against network issues
  4. Undo/redo management
  5. Version history

The mechanics of how text modifications are detected by the editor, relayed to the client provider, and subsequently disseminated to all collaborators will be expounded upon in the following sections.

3.7 Editor Bindings

(One User, One Notebook)

In building a platform that supports real-time collaboration, one must carefully consider the role of editor bindings. These components serve as the crucial links between the user and the shared data model. Simply put, editor bindings act as interpreters, transforming user actions—like keystrokes or cursor movements—into structured transactions within our shared data model.

Yjs creates a link between a broad spectrum of text editors, such as Monaco, CodeMirror, Quill, or Prosemirror, and its own data model through an intermediate binding layer. This binding allows for a seamless conversion between the data model of the editor and that of Yjs, with each client maintaining an independent copy of the Yjs data structure. This design not only facilitates Yjs in adeptly resolving potential conflicts but also guarantees that data remains consistent across all participating users.

While this ensures that the Yjs document remains in sync with our editors, we still had to create a unified view by synchronizing the shared model across all users.

3.8 Connection Providers

(Many Users, One Notebook)

Connection providers function much like editor bindings but on a larger scale. Within this infrastructure, there are two major components: client-side websocket providers and backend websocket providers.

Client-side providers are responsible for managing the user interface and handling user interactions within the application. This includes displaying updates in real-time as they are made by other users and ensuring every modification made by their user gets reliably and promptly communicated to the backend. To achieve this, they initiate and maintain a connection to the backend provider, so client-side providers guarantee that their user's view of the shared data model remains current with any new updates.

Backend providers are responsible for coordinating real-time data exchange on the network. They act as a broadcasting center, receiving messages from each client-side provider, processing them, and sending them back out to all other active clients. Essentially, backend providers ensure that all users remain synchronized.


Our system leveraged WebSockets as a communication protocol, with each active client initiating its own WebSocket connection to the backend. This setup efficiently handles real-time updates between users and the server, and ensures that changes are both sent and received promptly.

3.8.1 Unique Challenges of a Multi-Cell Notebook

Most collaborative applications following the editor/binding/provider pattern typically use one editor and one binding per CRDT-based document. Early experiments with the multi-cell notebook format required one provider per cell, with each editor bound to a unique Yjs Document (Y.Doc). Here’s a diagram illustrating this:

In this design, each editor requires its own connection, which can consume more resources and complicate synchronization between different parts of the application. In both Chrome and Firefox, delays in state updates and awareness data became evident as the number of cells grew to about 15 15-20, with each cell requiring a distinct WebSocket connection.

With Pennant, we took a more holistic approach. Careful inspection of source code and testing of the underlying data structure led us to integrate nested Yjs data types into our data model and establish a 1:1 ratio between an entire notebook and a Websocket-Provider . This not only reduced connection overhead but also resulted in a more efficient and cohesive system.

The resulting shared model structure looks more like this now:

Now, each notebook has a single Yjs Document (Y.Doc) and each cell is a Y.Map (similar to a javascript hashmap). This adjustment enabled our notebook structure, with our client-side provider efficiently handling updates to all nested data types and consolidating WebSocket connections to just one per client application instance.

3.8.2 Rooms

(Many Users, Many Notebooks)

In the context of real-time collaboration applications, 'rooms' play a pivotal role in managing and segregating collaborative spaces. The concept of 'rooms' is a metaphorical representation of a shared space where a group of users can collaborate on a single document. Each 'room' is identified by a unique 'room-name', and all users connected to the same 'room' can interact and collaborate in real-time.

Connection providers, which are responsible for synchronizing Yjs documents across multiple clients, utilize this concept of 'rooms' to manage synchronization scopes. When a Yjs document is connected to a 'room' via a connection provider, any changes made to that document are broadcasted to all other documents connected to the same 'room'. This means that all users connected to the same 'room' will have their views synchronized, enabling seamless collaboration.

This mechanism provides us with the flexibility to manage groups of collaborators working on different documents. For instance, we can have a 'room' for each document in our application, and any user who wishes to collaborate on a document would connect to the corresponding 'room'. This way, we can ensure that changes made by a user are only reflected in the relevant document and not broadcasted to unrelated documents, thereby maintaining the integrity and independence of each collaborative space.

3.9 Making it all work

In the previous subsections we defined the different pieces that real-time collaboration is built on. In this section, we show how those pieces work together to create a collaborative experience among users.

3.9.1 Synchronization and the client server model

With user interactions, editor bindings, and the connection provider working together, Pennant is able to synchronize state for both local and remote clients. The synchronization process works as follows:

  1. A user interacts with the application (by typing into an editor).
  2. The editor binding translates this into a modification on the shared data model.
  3. The connection provider broadcasts this modification to all connected peers.
  4. Upon receiving this modification, every peer provider integrates the change into its own version of the shared data model.
  5. Simultaneously, the editor binding reflects this alteration in the user's view.

This streamlined process ensures all instances of the application remain synchronized. The speed of this collaboration is made possible by the efficient data exchange facilitated by websockets and the optimized data handling of Yjs. This combination of technologies allows for changes to be propagated almost instantly, making the collaboration feel seamless and natural for all users collaborating within the same notebook.

3.9.2 Persistence

In Pennant, providing a seamless user experience goes beyond real-time synchronization; it also involves ensuring the reliable persistence of document states.

Our real-time collaboration backend keeps an in-memory copy of the document. When a new client wants to connect and sync to the current document state, it retrieves this state from the server. However, it's important to clarify that the server does not enforce a specific merged state on the clients. The incoming client independently merges updates into its own version of the document, following the rules defined by our CRDT model (Yjs in our case).

Our server discards the in-memory document once the last client disconnects. To ensure data persistence beyond the lifetime of active client connections, we’ve incorporated an additional persistence layer to our backend via AWS S3.

Whenever changes occur in a Yjs document, the updated state is encoded into a binary format (Uint8Array), which is optimized for data storage and transmission. This data is then persisted by our backend websocket provider, which leverages AWS S3 . When data retrieval is necessary, the binary data fetched from S3 is buffered and converted back into a string format, making it ready for use within the application.

To efficiently manage storage operations, we implemented debouncing in our saving strategy. If no edits are made by any user for five seconds, changes are saved to the backend. This approach ensures that during periods of rapid user input, we're not incessantly triggering saves. To prevent data loss of ongoing edits, we also have a fallback that enforces save operations every 30 seconds regardless of activity.

By maintaining this approach, we ensure that the latest state of the document can be reliably retrieved, facilitating uninterrupted collaboration over time and enabling users to resume their work seamlessly in future sessions. Furthermore, the high data durability offered by AWS S3 bolsters the security and accessibility of stored documents, reinforcing the reliability of our application.

4. Backend System Design for Real-Time Collaboration

In our mission to create a user-friendly, fast, and scalable computational notebook solution, we had to pay particular attention to managing server-side latency. This became especially relevant in scenarios where a large number of users were working concurrently on the same notebook.

Latency in collaborative tools is more than just a technical parameter; it's a determining factor of user experience. It sets the speed at which changes made by one client are propagated to all other connected clients. In the context of our application, where any user can execute code cells at any time, a high level of latency could interrupt workflow and impede the seamless collaborative experience we aimed to provide.

With these considerations in mind, we aimed for near-instantaneous propagation of changes. Our goal was to keep latency under 50ms for small teams of around 3-4 users, and strived to keep latency within an acceptable range for larger collaborations.

4.1 Challenges of Stateful Communication Protocols

Initially, we considered Fly.io, a cloud service that promises to "deploy app servers close to your users'', as an optimal solution to address basic scaling issues. We used Fly.io specifically for hosting our WebSocket backend, which was responsible for managing real-time collaboration between users.

However, as we began to stress-test our application, we uncovered an issue reminiscent of match-making in video games. Despite Fly.io's capabilities in spinning up new virtual machines for fresh instances of our WebSocket servers, clients working on the same document found themselves interacting with separate notebooks. This occurred because client requests, even though they bore the same room-name, were randomly assigned to different VMs .

The root of this issue was tied to the nature of our application being stateful rather than stateless, resulting in a need for session persistence. In simple terms, clients working on the same notebook needed to be consistently routed to the same VM instance. This need propelled us into an exploration of various approaches for scalable, session-consistent solutions.

4.2 Implementing a Stateful Backend

One of the primary challenges in horizontally scaling applications is managing stateful connections. Conventional load balancing approaches, which work well with stateless applications, falter when applied to stateful ones. The main shortcoming is their inability to ensure session persistence, as they generally distribute client requests evenly or based on server load, without consideration for previous session data. However, stateful applications such as ours need to ensure that a client's subsequent requests are routed to the same server where the session was initiated.

4.3 Existing Solutions

There are several established solutions for managing stateful applications at scale, including the utilization of popular orchestration platforms like Kubernetes or cloud-based solutions such as Amazon's Elastic Container Service (AWS ECS). These can effectively handle the deployment and scaling of stateful applications, including WebSockets, maintaining session persistence across multiple nodes and managing the state across restarts or rescheduling.

In tandem with these, Redis, an in-memory database system, is often used for its pub/sub mechanism. In the context of WebSocket connections, Redis serves as a message broker, broadcasting all messages to all servers to ensure they remain synchronized and state consistency is preserved. However, effective implementation requires careful orchestration to ensure all servers remain in sync.

4.4 Our Solution

In contrast to the aforementioned frameworks, we chose to leverage Nginx's built-in consistent hashing mechanism for managing stateful connections at scale. This approach works by calculating a hash based on the request URI, inclusive of the document ID, and uses the resultant hash to guide the routing decision, effectively maintaining session 'stickiness'.

To enable horizontal scaling, we've reconfigured our system to run each instance of our WebSocket server backend on separate DigitalOcean droplets. Nginx, hosted on a third droplet, is fine-tuned to distribute the hash space evenly across the backend servers, effectively balancing the load.

Each server URL now includes a dynamic path: wss://server-domain/collab/:docID. The constant hash for a specific docID ensures clients requesting a certain notebook are consistently routed to the correct server, providing session consistency. This setup proves resilient even during server outages, as Nginx redistributes the hash space across the remaining servers, maintaining session 'stickiness'.

Testing this configuration confirmed its effectiveness. Notably, an additional client joining an existing session was correctly routed to the appropriate server, reinforcing the success of our approach.

5. Execution Engine

The previous section describes the design choices we made to keep our app collaborative in real time. Most collaborative apps only need to sync the state of the app as a whole. However, the unique nature of a collaborative coding notebook requires that Pennant’s collaboration service track the state of each of the cells separately.

The fact that Pennant is a collaborative coding notebook also added unique requirements to our code engine. This section will delve into the design of Pennants collaborative code execution engine. Some of its parts were informed by the generic needs of all code execution engines. Others fulfill more specific needs of notebook-style code execution. Finally, the requirement of real-time collaborative code execution impacted the design of the engine, server-hosting and deployment of our engine service, which will also be discussed.

5.1 Running code through a remotely hosted code editor

Often, it is easier to test code on a remotely hosted code editor than on your own machine. Users can enter code directly on a website and receive the results by pressing play. However, since the remote host runs code from multiple users, running complex user code from one user can potentially hold up the execution of others’ code or drain all the server’s resources away from other users.

5.1.1 Queuing up user inputs

The time it takes to execute code from each client depends on numerous factors, such as server load and code complexity. In a synchronous API, the server and client must hold a connection open until the code is executed. If each request takes several seconds to resolve, the server can experience heavy load increasing the likelihood of dropped connections and timeouts. From a user perspective, this can cause frustrating delays due to head-of-line blocking.

Therefore, we chose an asynchronous design for our API. When a user clicks a cell’s run code button, the client sends a POST request to our API containing the cell contents. Upon receipt, the API sends code execution instructions to a queue for workers to process asynchronously. Then it immediately sends the client a 202 Accepted response containing the submissionId. Rather than spending system resources on leaving connections open, this design frees up the server to handle other requests quickly. This makes our engine robust and creates a better experience for end users.

5.1.2 Returning the results to users

The client can use the submissionId as a token to query the status of the execution in subsequent requests. To receive the output code, the client polls the GET status route. Then the server checks a cache for the processed output of the submission. On successful executions, the server sends a payload containing the results of the executed cells, including log outputs, syntax issues, or runtime errors. Finally, the client renders execution results below the code cells that generated them. If results are unavailable, the server sends a pending status to the client, and the client may poll on a short interval until the execution is processed or there is a failure.

Errors are not uncommon due to the unpredictability of networked applications and user-provided code. If the code execution worker fails to update the cache within a configured timeout window, the API assumes that an execution error occurred and sends a critical error message to the client. The submission ID is marked as failed, and the frontend alerts the user to execute the code again.

5.2 Why remote code execution engines use workers

The whole purpose of our code execution engine’s architecture at a high level is to leverage the use of workers.

High-level overview of the worker

As mentioned previously, the advantage of workers is that they run code in the background, freeing up the API server to handle requests at a faster speed. However, workers also provide an equally important benefit of functional partitioning which is leveraged to enhance security. Specifically, workers’ functional isolation allows us to encapsulate each in stronger layers of isolation and shield our app from the effects of the code run in each worker.

5.3 Containerization for resource control

A container deployment tool, Docker, helps us create and manage code-execution workers as containers. Isolated yet lighter weight than virtual machines, containers are processes running on a shared kernel belonging to a host machine. This makes them optimal for our use case since we can create a containerized worker for each notebook, isolating code execution processes across users.

Let's contrast this with a non-containerized approach. If we ran all user code on a single node process, a compute-intensive operation such as an infinite loop would crash the entire application, disrupting service for all users. By dedicating a containerized process to each notebook, one notebook’s worker can fail without affecting the experience of other users.

Although containing code execution processes prevents engine crashes due to user code, containers still run on a single host machine. If the host tried to open too many containers at one time, the server would overload itself with containers and crash, meaning any user that had been attached to any container on that server would be unable to run code.

To maintain overall system health, we allocate a maximum of 100 MB of RAM to each container and prevent new containers from being created if free RAM is less than 20%. Containers also self-terminate if they have not executed code in the last 15 minutes.

5.4 Sandboxing for security

While they limit resource drain from both malicious and non-malicious users, docker containers have been proven to be vulnerable to other attacks from malicious users.

Escapes are attacks that exit an intended context, allowing attackers to run malicious code. SQL injection attacks are one such example. Suppose a server adds user-input fields into SQL commands and executes it without sanitizing inputs. An attacker could use syntactical characters to break out of an intended data manipulation command and execute dangerous commands like dropping or querying user tables.

Similarly, there is the possibility to escape from the isolation provided by a container. In the worst case, container escapes could grant attackers control of the host machine, allowing them to deploy malicious containers or obtain sensitive user data. In 2019, cryptocurrency mining malware breached multiple Docker-driven APIs, took over their containers, and replaced them with attacker-controlled mining processes. The attackers exploited the privileged Docker option, which grants containers root access to the host machine (link).

With root access, attackers can escape a container by simply mounting the host /dev folder, allowing them to manipulate storage, memory, and network interfaces. Therefore, running containers with the privileged option or as the default root user is strongly discouraged in production. However, even if a container runs without root access, attackers can exploit Linux system vulnerabilities to escalate their permissions and gradually gain control of the host system [4].

One option for addressing these vulnerabilities would be gVisor, which provides a runtime for isolating containers in a virtualized kernel. This creates an additional separation layer between workers and the host kernel that intercepts system call exploits, preventing container escapes. We had originally read that gVisor’s runsc runtime runs with a 15 mb memory footprint [5]. However, our tests showed gVisor doubled the memory consumption of our containers.

RAM per container Max # of concurrent workers per host
runC 25 MB 40
runsc 60 MB 18

Instead, we strengthened our security without introducing more resource demands by modifying our Docker configurations, significantly minimizing the attack surface.

  • Configuring containers to run under unprivileged non-root users
  • Dropping all Linux kernel capabilities to prevent common privilege escalation attacks [6]
  • Setting the entire file system of the container as read-only, preventing attackers from injecting hostile scripts

Our configuration does not prevent container escapes to the same extent as gVisor since our server’s host kernel is still accessible to some degree. In the extremely rare case that an escape occurs, the damage that could be inflicted on the host is significantly limited by disabling privilege escalation.

A more realistic concern is that untrusted code can break out of the sandboxed execution context and gain visibility into the worker process itself. Such an escape can expose secrets stored in process environment variables, so our architecture limits the credentials shared with our workers. For example, to send results workers must communicate with a separate process that writes to a remote cache on their behalf.

6. Remote execution: Notebooks vs Code Editors

In a code editor, all the code runs each time the code is executed. In contrast, computational notebooks can run pieces of code in isolation. As a result, computationally heavy sections do not need to be rerun if they haven’t been changed, which can save up to hours of time.

6.1. Long-lived vs Short-lived workers

To allow Pennant to execute code as cells, we deviated from other code-execution engine models by opting for long-lived execution environments. Each worker remains active throughout a user session and is dedicated to processing requests from a single notebook.

Most code execution engines use short-lived workers because they conserve resources by spinning down when not being used. However, the tradeoff is that there are code execution delays due to cold starts. Workers have to be rebuilt and restarted before each execution.

Our engine employs long-lived workers to persist stateful execution contexts, allowing flexibility and also minimizing execution times . Although this design decision requires additional resources to maintain idle workers, it emulates an experience akin to using native JavaScript. It also allows our engine to be fully collaborative. This decision adds complexity to our design, which we will discuss in more detail later.

The next few sections are a walkthrough of how our workers handle code execution requests. We'll begin by explaining the initialization of execution processes and their association with each notebook. Afterwards, we'll discuss script cleaning, which enables users to run JavaScript code cell by cell, bypassing inherent language restrictions. Lastly, we'll discuss the specifics of executing code against a stateful environment and establishing a first layer of secure execution. At each logical step, we'll discuss alternative methods and explain why they lead us to our current implementation.

6.2. Queues, HoLB

A side effect of long-lived workers with different states is the need to route user requests to the correct worker. We created dedicated queues for each notebook, preventing a head-of-line blocking issue that would occur if all notebooks consumed from a single queue. This issue is due to our design of long-lived containers dedicated to each notebook,which means all requests from the same notebook must process sequentially through a single worker . With only one queue, requests from other notebooks would face unnecessary delays, despite the availability or potential for other workers to handle them instantly. To circumvent this issue, which is specific to long-lived and stateful workers, we created a separate queue for each worker. Now, If one notebook is executing long-standing code, it only blocks subsequent code from the same notebook.

6.3. Script Cleaning for Enabling Notebook-style Execution

Computational notebook users can experiment with code by editing and re-running the same code cells multiple times. From JavaScript’s perspective, however, re-running a cell that contains a redeclaration of an existing variable name means the developer made a mistake, so it throws a syntax error. Therefore, Pennant required a feature that circumvented variable declaration syntax errors to enable users to run code cells seamlessly.

One solution could have been a reserved namespace object that makes variables visible to other cells via object properties and methods. However, this diverges significantly from vanilla JavaScript and doesn't support a genuinely stateful execution environment across cells (in-memory states such as closures and object prototypal inheritance are not supported). Some web development notebooks ban the const and let keywords entirely to make variable declaration syntax errors impossible. However, this also prevents users from block-scoping variables, a fundamental mechanism in modern JavaScript.

Pennant’s solution allows users to use standard JavaScript, by cleaning the code in the background to balance flexible execution with standard JavaScript language conventions.Specifically, any top-level let declaration will be modified into a reassignment when a user re-runs that declaration’s original cell. For example, running the code cell let foo = “bar” the first time declares a variable as expected. On the second run, it is executed as a variable reassignment: foo = “bar”. If a user tries to redeclare foo elsewhere in the notebook, the engine throws a syntax error appropriately.

6.4. Executing the code in chunks

In order to allow the user to run code as cells, the main optimization we made was to store, accumulate and apply context data from previous runs. Our engine does not need to rebuild the entire execution context at each run as normally happens in javascript’s runtime environment. This means we don’t need to run all the code each time, which allows us to skip computationally heavy code, which makes the speed of code execution much faster. This allows us to execute small pieces of code that have awareness of and reference the global (accumulated) context, meaning code submitted in pieces gives the same results as re-submitting all the code top to bottom, but executes faster.

We used the vm2 library to accumulate and persist an execution context object in each worker based on the previous runs. Vm2 wraps the core node vm library, which allows node processes to execute scripts against a custom execution context object, instead of the main environment object of the actual process.

We were able to replace a large portion of our execution engine, which attempted to do this manually, running scripts as child processes while building the context object itself and storing it in memory. Utilizing child processes directly left a major security vulnerability in our application since user code would have access to the parent node process environment. By executing code against a custom context object, vm2 provides a first-level sandboxing layer at a lower level than our container sandbox configuration.

7. Tradeoffs of long-lived workers

As discussed, executing code as individual cells from a given notebook lowered the computational load of our architecture. We explained how long-lived workers with accumulated state about prior code executions were necessary to be able to run code in small chunks.Long-lived workers, however, use more server resources to keep the workers alive between runs.

We contemplated saving resources by spinning workers up and down for each execution, and storing notebook specific context data in a database. However, the shutdown and restart of containers noticeably slowed the execution of our code engine.

We chose to keep the containers long-lived as this allowed faster execution speeds which is the main advantage of using notebooks .

8. Why we can’t allow users to run code on their own machines

Client-side code execution, while fast, poses significant challenges for collaboration.

Unlike document editing, stateful code execution isn't commutative. Running the same set of code cells in varied sequences will yield different results. Therefore, to ensure consistent outputs, the order of code execution must remain constant across users. Our remote engine's architecture addresses this by employing queues and executing the code against shared stateful environments.

A potential client-side solution to the state synchronization problem would have been to designate a primary, client-hosted engine among collaborators. This approach could have brought additional browser-centric features to Pennant, such as integration with browser APIs or rendering of frontend outputs similar to platforms like CodePen. However, the complexities of executing untrusted code on users’ browsers, managing unstable connections, and addressing browser compatibility concerns rendered this option impractical to implement within our project’s timeframe.

9. Final architecture walk through

Let’s take a step back and look at the final architecture. There are three services, which the user interacts with separately, so let’s step through the web server, collaboration services and execution engine in rough chronological order .

Our web server handles logging the user into their dashboard . The dashboard contains links to all of their previously created notebooks, as well as a link to create a new notebook. This service relies on a DynamoDB database which can retrieve notebook names and ids.

When a user initially accesses a notebook, they are using another service, the collaboration service. A load balancer will route them to a websocket server, called the provider server.

Now they are connected to other users of the notebook, or waiting for other users to connect to them.

If the notebook is in use, the notebook is already in memory in the provider server. If the notebook is not in use, the provider server will fetch the notebook from the AWS S3 document datastore. When the last user of a notebook disconnects, the notebook is saved back to the database and is removed from memory on the server.

When a user submits code, that code is sent to a third service, the code execution service. Their code is routed through an API server to the correct docker container dedicated to their notebook. This service is asynchronous, which in our case means the user polls for their results. These results first go to one client only, then are shared out to other users through the collaboration service.

This is our final architecture, together in one diagram:

10. Next Steps

In the previous section, we walked through the current infrastructure of Pennant. We illustrated how each of our microservices work together to create our user experience. In this section, we will talk about our vision for the future of Pennant which is the efficient scaling of both our notebook collaboration service as well as our code execution engine.

10.1 Scaling

The main issues for scaling our application all revolve around the stateful nature of our websocket connections and our engine’s workers. Normally scaling relies on stateless communication between server and client, so that the client’s request can be routed to any of a number of servers and receive the same response .

10.1.1 Scaling collaboration

While our current solution provides an effective mechanism for handling stateful WebSocket connections at scale, we recognize the need for further enhancements. As we continue to evolve our project, we're looking to integrate dynamic scalability features. This includes the exploration of orchestration services such as AWS ECS or managing a DigitalOcean Kubernetes Service (DOKS) cluster. Concurrently, a system like Redis could also play a role in these future developments to maintain state synchronization across nodes. This represents an exciting area of focus for our next steps.

10.1.2 Scaling the execution engine

Scaling the execution engine is a challenge due to the difficulty of converting workers into stateless processes. Our current worker node is hosted on a medium-spec Digital Ocean droplet that supports a limited number of 30 concurrent, long-lived processes. Additional worker nodes can be brought online as needed but at high costs.

It is impossible to serialize execution context objects without discarding numerous in-memory entities within a JavaScript environment. For instance, object prototype chains, closures, and circular references cannot be serialized with existing tools. Since one of Pennant’s goals is simulating a close-to-native JavaScript experience, making the engine stateless is not an option.

It is possible to significantly reduce the memory consumption of our workers by using V8 isolates as an alternative to containerized processes. Isolates sandbox code execution at a lower level, effectively isolating multiple execution workers as concurrent threads within a single process. Platforms like Cloudflare currently use V8 isolates to securely execute code on their servers.

10.2 Additional code execution features

In addition to working on scaling issues, we would like to integrate client-side execution as an option. Client-side execution could unburden our infrastructure and bring front-end coding features to Pennant. For example, using a notebook to test and document external APIs, or rendering frontend primitives such as React. While we alluded to security challenges in the last section, iframe-based sandboxing can isolate browser environments from dangerous front-end code.

References

  1. Davies, A., Hooley, F., Causey-Freeman, P., Eleftheriou, I., & Moulton, G. (2020). Using interactive digital notebooks for bioscience and informatics education. PLoS Computational Biology, 16(11), e1008326. doi: 10.1371/journal.pcbi.1008326.

  2. Kim, B., & Henke, G. (2021). Easy-to-Use Cloud Computing for Teaching Data Science. Journal of Statistics and Data Science Education, 29(Supplement 1), S103-S111. doi: 10.1080/10691898.2020.1869022.

  3. Observable JavaScript. ObservableHQ. Accessed Jul. 2023.
  4. Roguski, P., & Baker, D. (2022). Containers vulnerability risk assessment. Red Hat Blog. Retrieved from https://www.redhat.com/en/blog/containers-vulnerability-risk-assessment.

  5. Young, E. G., Zhu, P., Caraza-Harter, T., Arpaci-Dusseau, A. C., & Arpaci-Dusseau, R. H. (Year). The True Cost of Containing: A gVisor Case Study. In Proceedings of the 11th USENIX Conference on Hot Topics in Cloud Computing (HotCloud'19). University of Wisconsin, Madison.

  6. Avrahami, Y. (2022, Mar. 3). New Linux Vulnerability CVE-2022-0492 Affecting Cgroups: Can Containers Escape? Unit42. Retrieved from https://unit42.paloaltonetworks.com/cve-2022-0492-cgroups/.

  7. Building Realtime Collaborative Apps. (2016-2023). CONVERGENCE LABS, INC. Retrieved from https://convergencelabs.com/blog/2017/02/building-realtime-collaborative-applications/.

  8. Yang, Z. (2021, Nov 13). Exploration of Collaborative Editing Technology. Retrieved from https://pubuzhixing.medium.com/exploration-of-collaborative-editing-technology-b2f4c41c31ff.

  9. Choosing a Realtime Collaboration Library. (2016-2023). CONVERGENCE LABS, INC. Retrieved from https://convergencelabs.com/realtime-collaboration-technology-guide/.

  10. Enes, V., Almeida, P. S., Baquero, C., & Leitão, J. (2019, Mar 11). Efficient Synchronization of State-based CRDTs. Retrieved from https://arxiv.org/abs/1803.02750.

  11. Jahns, K. (2021, Jun 4). How we made Jupyter Notebooks collaborative with Yjs. Retrieved from https://blog.jupyter.org/how-we-made-jupyter-notebooks-collaborative-with-yjs-b8dff6a9d8af.

  12. Quaranta, L., Calefato, F., & Lanubile, F. (2022, April). Eliciting Best Practices for Collaboration with Computational Notebooks. Proc. ACM Hum.-Comput. Interact., Vol. 6, No. CSCW1, Article 87. Retrieved from https://arxiv.org/abs/2202.07233.

  13. Scaling live experiences: Horizontal vs vertical scaling for WebSockets. Retrieved from https://ably.com/blog/websockets-horizontal-vs-vertical-scaling.

Presentation

Meet our team

We are currently looking for opportunities. If you liked what you saw and want to talk more, please reach out!

  • Judah Landzberg

    Baltimore, MD, USA

  • Michael Ricasa

    San Francisco, CA, USA

  • Marwan Zaarab

    Toronto, ON, Canada

  • Richard Cole

    Seattle, WA, USA
